Thermoform Machines

With 26 years of experience, Betapak delivers thermoforming machines that heat polymer film and vacuum-form it into precise packaging shapes — fully integrated with filling, sealing, and MAP technology for a complete production line from a single source.

Our machines are built for fresh meat, poultry and seafood, dairy products, ready meals, bakery and portion products, and water & juice lines, producing package formats such as MAP trays, vacuum-sealed trays, cups and IML-labelled containers — matched to the film, mold and capacity requirements of each production line.

Vacuum Thermoforming

Film pulled over molds by vacuum — ideal for complex, high-detail shapes.

Pressure Thermoforming

High-pressure air forming for larger, more durable packaging formats.

Mechanical Thermoforming

Mold and press-plate mechanics for high-speed mass production lines.

Fully Automatic

End-to-end automated thermoform packaging with minimal operator input.

Request Information

Thermoform Machines

Thermoform
Machines

A thermoform packaging machine forms the package, fills it and seals it in a single continuous line. Instead of buying ready-made trays or cups, you feed reels of film: the bottom film is heated and formed into cavities, the product is placed or dosed into each cavity, a lid film is sealed on, and the finished packs are cut and discharged.

What it solves. Manual tray handling and separate forming, filling and sealing stations are replaced by one hygienic, repeatable process. Pack size and seal quality stay consistent from the first pack to the last, the right atmosphere inside the pack protects product shelf life, and one line can run different formats by changing the mold.

Types of thermoform packaging.

  • Vacuum: air is removed from the pack before sealing — a compact, practical format for many food products.
  • MAP (Modified Atmosphere Packaging): the air is replaced with a gas mix matched to the product, for fresh meat, poultry, dairy and ready meals. See the Bpz Series.
  • Skinpack: a skin film follows the product shape for firm protection and strong shelf presentation. See the Skinpack Series.
  • FFS (form-fill-seal): cups or trays are formed, filled and sealed in one cycle — typical for dairy, sauces and beverages. See the Bpt Series.

This page covers thermoform packaging machines. Machines that form heavy plastic sheet into trays, housings or other products are a different category and are not covered here.

Machine Series Comparison

Series Best-Fit Products Packaging Format Film Compatibility Sealing Technology Automation Level
Starter Series Dairy, bakery and portion products for growing production lines Cup and tray sealing Standard PP / PET films Vacuum and MAP-ready Automatic tray sealer / cup filling
Bpz Series Fresh meat, poultry, seafood, dairy and medical products Thermoformed MAP / vacuum trays Multilayer barrier films Vacuum and MAP application Fully automatic
Bph-S Lineer Meat, dairy and ready meals on linear production layouts Linear tray sealing Barrier tray sealing films Vacuum and MAP application Fully automatic linear tray sealer
Bpt Series Dairy (yoghurt), water & juices, IML-labelled products Cup filling / FFS PP / PS cups, IML labels Heat-seal / FFS Fully automatic FFS line

Output capacity depends on tray/cup size, film and product — see the model values below, or request a configuration for your product.

Thermoform Machine Models

Starter Series

BPZ JR Thermoform Machine

Compact, economical machine with chain feed for food and medical packaging.

Cycle speed5 – 7 cycles/min View model
Bpz Series

Z 105 Thermoform Machine

Youngest and most economical Betapak machine, built for small-capacity single applications.

Technical dataSpecs on request View model
Bpz Series

BPZ 400 Thermoform Machine

Flexible MAP-capable line with precise dosing for small and large scale production.

Cycle speed6 – 12 cycles/min View model
Bpz Series

BPZ 400 MAX Thermoform Machine

Wider format version for dairy desserts and bakery products with optional lid films.

Cycle speed6 – 12 cycles/min View model
Bpz Series

BPZ Joy Box Line Thermoform Machine

Fully automatic line for surprise eggs and confectionery with ultrasonic sealing.

Cycle speed18 – 20 cycles/min View model
Bpz Series

BPZ 400 Medical Thermoform Machine

Healthcare-focused configuration with medical-grade lid film options.

Cycle speed10 – 14 cycles/min View model
Bph-S Lineer

BPH-S Lineer Thermoform Machine

Compact linear tray sealer with flexible recipe management for multiple products.

Cycle speed8 – 14 cycles/min View model
Bpt Series

BPT JR Thermoform Machine

Compact, high-capacity cup line for honey, ketchup, mayonnaise and sauces.

Cycle speed18 – 22 cycles/min View model
Bpt Series

BPT-P Thermoform Machine

Flexible FFS line with precise dosing for small and large scale production.

Cycle speed20 – 28 cycles/min View model
Bpt Series

BPT-S Thermoform Machine

High-capacity servo-driven line for water and dairy products.

Cycle speed20 – 28 cycles/min View model
Bpt Series

BPT-Y Thermoform Machine

Sterile packaging with HEPA filtration and servo control for dairy and sensitive products.

Cycle speed20 – 28 cycles/min View model
Bpt Series

BPT-Y IML Thermoform Machine

BPT-Y with in-mold labeling (IML) for sterile dairy packaging.

Cycle speed24 – 25 cycles/min View model
Bpt Series

BPT Complete Line Thermoform Machine

High-capacity complete line with automatic cartoning and zero-waste cutting.

CapacityUp to 50,000 units/hour View model

Key Technical Values by Model

Model Cycles / min Film width Step length Max. forming depth Electrical
BPZ JR 5 – 7 250 – 422 mm 80 – 120 mm max. 75 mm max. 10 kW, 380 V
Z 105 — — — — —
BPZ 400 6 – 12 250 – 462 mm 210 – 400 mm max. 85 mm (standard) / 150 mm (private) —
BPZ 400 MAX 6 – 12 250 – 600 mm 200 – 600 mm max. 85 mm —
BPZ Joy Box Line 18 – 20 250 – 400 mm 150 – 200 mm — —
BPZ 400 Medical 10 – 14 250 – 462 mm 80 – 400 mm max. 80 mm —
BPH-S Lineer 8 – 14 — — max. 200 mm 10 – 15 kW, 380 V
BPT JR 18 – 22 — — max. 50 mm max. 15 kW, 380 V
BPT-P 20 – 28 — — max. 95 mm max. 15 kW, 380 V
BPT-S 20 – 28 340 – 405 mm 140 – 320 mm max. 80 mm —
BPT-Y 20 – 28 220 – 410 mm — 90 mm max. 18 kW, 380 V
BPT-Y IML 24 – 25 220 – 410 mm — 90 mm max. 18 kW, 380 V

Values are taken from each model's product page. One cycle forms one step of packs, so packs per minute depend on the mold layout. “—” means the value is not published on the product page; ask Betapak for the figure for your product.

Solution Scenarios

Fresh Meat & Poultry: Longer Shelf Life

Fresh meat and poultry spoil quickly and are highly sensitive to oxygen exposure. Betapak thermoforming lines apply Modified Atmosphere Packaging (MAP) to replace the package atmosphere with a protective gas mix, extending shelf life without preservatives while keeping color and freshness intact for retail display.

Recommended: Bpz Series

Dairy Products: Leak-Proof, Hygienic Sealing

Liquid and semi-liquid dairy products demand a fully leak-proof seal to prevent contamination and spoilage in transit. Our thermoform machines create a tight, uniform seal on every cycle, meeting hygiene standards for cheese, yogurt, and portioned dairy items.

Recommended: Bpt Series / Starter Series

Ready Meals: Multi-Compartment Trays

Prepared and portioned foods often need multiple ingredients kept separate until use. Betapak machines form multi-compartment trays in a single cycle, keeping sauces, sides, and mains apart while sealing everything securely for retail-ready presentation.

Recommended: Bph-S Lineer

Medical Devices: Sterile Barrier Packaging

Medical device packaging must maintain a validated sterile barrier from production through end use. Our machines are configured for cleanroom-compatible operation and precision sealing, ensuring consistent, sterile-safe packaging for medical and pharmaceutical products.

Recommended: Bpz 400 Medical

Bakery & Portion Products: High-Speed Small Formats

Small-format bakery and portion products require high cycle speeds without sacrificing pack quality. Betapak's fully automatic lines handle high-throughput, small-tray formats for pastries, snacks, and portioned goods with consistent seal quality at speed.

Recommended: Starter Series

Sustainable Packaging: Recycled & Biodegradable Films

Manufacturers under pressure to cut plastic waste need machines that keep seal integrity with alternative materials. Betapak thermoforming machines run recycled PET, bio-based, and compostable films without compromising package strength or shelf life.

Water & Juices: High-Speed Cup Filling

Water and juice lines need fast, hygienic cup or FFS filling with a reliable seal at continuous line speed. Betapak's Bpt Series forms, fills, and seals cups in a single automated cycle for beverage producers.

Recommended: Bpt Series

How to Choose the Right Machine

  • 1
    Product & tray dimensions

    The size, shape and weight of your product determine the mold and forming area required.

  • 2
    Target output capacity

    Current and planned production volume decides whether an entry-level or high-capacity series fits your line.

  • 3
    Film width and mold

    Film reel width, thickness and cavity depth must match the final package format.

  • 4
    MAP or vacuum requirement

    Shelf-life targets and product sensitivity define whether MAP, standard vacuum, or both are needed.

  • 5
    Filling and dosing needs

    Liquid, solid or multi-compartment products may require an integrated filling system.

  • 6
    End-of-line integration

    Labelling, cartoning and downstream handling equipment should be planned together with the thermoforming machine.

Frequently Asked Questions

A thermoforming machine heats a plastic film until pliable, then uses vacuum or pressure to form it tightly over a mold. The shaped tray is filled with product, sealed with a top film, and cut to size — all in a continuous, automated cycle.

Thermoforming machines are widely used in food (fresh meat, dairy, ready meals), medical device packaging, and industrial component packaging. Betapak offers thermoforming solutions tailored to each of these sectors.

Vacuum thermoforming removes air from the package before sealing, extending shelf life for many products. MAP (Modified Atmosphere Packaging) replaces the internal atmosphere with a controlled gas mix (e.g., CO₂/N₂) — ideal for fresh meat and produce, offering even longer shelf life without preservatives.

Yes. Betapak thermoforming machines are compatible with a wide range of sustainable film materials including recycled PET, bio-based films, and compostable laminates — helping manufacturers meet environmental targets without compromising seal integrity.

Key factors include your required output capacity, package format and tray dimensions, product type (food, medical, industrial), and whether MAP or vacuum application is needed. Betapak's engineering team provides a free consultation to match the right machine to your requirements.
